VL53L0X TOF Laser Distance Sensor – High-Accuracy LIDAR Module:

The VL53L0X Time-of-Flight (TOF) LIDAR Laser Distance Sensor from Robo Pixel is an ultra-accurate ranging module designed for robotics, automation, drones, and smart IoT systems. Unlike traditional IR sensors, this advanced TOF sensor measures the actual time light takes to reflect from an object, providing precise, fast, and reliable distance measurement even in challenging conditions.

Package Includes

• 1 × VL53L0X TOF Laser Distance Sensor Module

• 1 × Header Pin Set (Unsoldered)

Technical Specifications

• Sensor Type: Time-of-Flight LIDAR

• Operating Range: 20mm – 2000mm

• Accuracy: ±3% (depending on conditions)

• Interface: I²C (up to 400kHz)

• Voltage: 2.6V – 5V

• Field of View: ~25°

• Sampling Rate: Up to 50Hz

• Operating Temperature: -20°C to 70°C

• Dimensions: Ultra-compact module
