ADS1115 16-Bit ADC- 4 Channel with Programmable Gain Amplifier:
The ADS1115 is a precision, low-power, 16-bit analog-to-digital converter (ADC) with an integrated programmable gain amplifier (PGA). Featuring four single-ended or two differential channels, the ADS1115 delivers highly accurate digital conversion for analog sensors and signals in compact embedded applications.
This powerful and compact ADC is ideal for microcontroller projects where high-resolution analog input is required, including Raspberry Pi, Arduino, ESP32, and STM32 based systems.
Why Choose the ADS1115?
The ADS1115 offers the perfect combination of resolution, flexibility, and ease of use. Whether you're a hobbyist, engineer, or educator, this ADC simplifies analog signal integration and improves measurement accuracy in your projects. Its programmable gain amplifier allows for direct reading of small sensor signals without needing external amplification circuitry.
Technical Specifications
| Parameter | Specification |
|---|---|
| Resolution | 16 bits |
| Channels | 4 single-ended / 2 differential |
| Interface | I2C |
| Input Voltage Range | ±6.144V (configurable via PGA) |
| Data Rate | 8 to 860 SPS |
| Supply Voltage | 2.0V to 5.5V |
| Current Consumption | ~150 µA |
| Operating Temperature | -40°C to +125°C |
| Package Type | 8-pin SOIC or module |
-
Easy Returns
-
Quality Service
-
Original Product
Applications
-
Sensor Data Acquisition
-
Industrial Automation
-
Medical Instrumentation
-
Battery Monitoring Systems
-
Embedded Systems & Robotics
-
IoT Devices
-
Portable Measurement Tools
Buy Now
Bring precision to your analog measurements—order the ADS1115 16-Bit ADC Module today and enhance your data acquisition capabilities!
